Form Deck
Form deck streamlines concrete slab pours while containing costs
Permanent formwork for concrete slabs without composite action
Form deck is the workhorse of floor construction. Form deck is used extensively as an economical form to support concrete slabs during erection. In some cases, form deck eliminates the need for expensive temporary deck shoring.
UL- and ULC-approved and listed in the UL and ULC Fire Resistance directories.Conforms to ASTM A1008/ A1008M for uncoated and painted deck, and A653/A653M for galvanized deck. Meets required steel deck certifications in accordance with Steel Deck Institute (SDI) specifications.
Form Deck
Form deck is available in lengths from 6 feet to 40 feet. Please check with your local New Millennium facility for lengths outside these parameters. Form deck holds a yield strength up to 80ksi. Refer to the Steel Roof and Floor Deck design guide for the minimum yield strength for each steel deck type. Contact New Millennium for availability of higher yield strengths when required or use our deck specification tool to view load tables with commonly available non-standard yield strengths and/or gages.
0.6" Form Deck
Type 0.6FD form deck is used extensively in floor construction as an economical form to support concrete slabs during steel construction projects. Specifying 0.6FD floor deck may eliminate the need for expensive temporary shoring. Floors using 0.6FD floor deck are among the most economical available.
0.6" Form Deck (FD)
0.6" Form Deck (FDV)
- Available with nested side-laps only
- Available as a vented deck, 0.6″ Form Deck (FDV) is manufactured with slot vents in the bottom flutes, the openings equal 0.5% of the total surface
- 0.6” FD and 0.6” FDV are UL-approved; 0.6” FD is ICC-approved
1" Form Deck
Type 1.0FD form deck is used extensively in floor construction as an economical form to support concrete slabs during steel construction projects. Specifying 1.0FD deck may eliminate the need for expensive temporary shoring. Floors using 1.0FD deck are among the most economical available.
1" Form Deck (1.0FD)
1" Form Deck (1.0FDV)
- Available with nested side-laps only
- Available as a vented deck, type 1.0FDV is manufactured with slot vents in the bottom flutes, the openings equal 0.5% of the total surface
- 1.0FD and 1.0FDV are UL-approved; 1.0FD is ICC-approved
1.5" Form Deck
1.5″ form deck is used extensively in floor construction as an economical form to support concrete slabs during steel construction projects. Specifying 1.5″ form deck may eliminate the need for expensive temporary shoring. Floors using 1.5″ form deck enable the designer to space the structural members to over 10 feet on center.
1.5" Form Deck (1.5FD)
1.5" Form Deck Reversed (1.5FDR)
1.5" Form Deck Vented (1.5FDV)
1.5" Form Deck Interlocking (1.5FDI)
1.5" Form Deck Interlocking Vented (1.5FDIV)
- 1.5FD is available with nested side-laps only
- Types 1.5FDR and 1.5FDV available with nested side-laps, types 1.5FDI and 1.5FDIV available with interlocking side-laps
- Available as a vented deck, types 1.5FDV and 1.5FDIV are manufactured with slot vents in the bottom flutes, the openings can be specified from 0.5% to 1.5% of the total surface
- Also available with rolled-in hanger tabs (non-vented types only)
- 1.5FD is ICC- and UL-approved
- 1.5FDR, 1.5FDV, 1.5FDI, and 1.5FDIV are UL-approved; 1.5FDR and 1.5FDI are ICC-approved
2" Form Deck
Type 2.0FD form deck is used in floor construction as an economical form to support concrete slabs during steel construction projects. Floors using 2.0FD deck enable the designer to space the structural members to over 14 feet on center without additional shoring.
2" Form Deck (2.0FD)
- Available with interlocking side-laps only (extended side-laps can be provided upon request to facilitate screw installation)
- Also available with rolled-in hanger tabs
- 2.0FD Form Deck is ICC- and UL-approved
3" Form Deck
Type 3.0FD form deck is used in floor construction as an economical form to support concrete slabs during steel construction projects. Floors using 3.0FD deck enable the designer to space the structural members to over 16 feet on center without additional shoring.
3" Form Deck (3.0FD)
- Available with interlocking side-laps only (extended side-laps can be provided upon request to facilitate screw installation)
- Also available with rolled-in hanger tabs
- 3.0FD Form Deck is ICC- and UL-approved
